World Trade SpA - Official European Distributor
TMGT-OTL42FH
42" REAR TOUCH MONITOR
42” TouchMonitor
Wo r l d L e a d i n g
To u c h S o l u t i o n s
P r ov i d e r
OTL424-A
Monitor Datasheet
Rev:1.1
www.generaltouch.com
Touch Your IMAGINATIONToday
World Trade SpA
- Via della Lontra, 43 - 47923 Rimini Italy
Tel. +39 0541 75.33.44 - Fax +39 0541 75.33.38 - [email protected]
www.worldtrade.it
World Trade SpA - Official European Distributor
TMGT-OTL42FH
42" REAR TOUCH MONITOR
Wo r l d L e a d i n g
To u c h S o l u t i o n s
P r ov i d e r
Specification:
www.generaltouch.com
Model
Description
Case/Bezel Color
Monitor Performance
Display Type
Active Display Area
Native Resolution
Sychronization Range
Pixel Pitch
Pixel Response Time
Plug and Play
On Screen Display(OSD)
Colors
Brightness(LCD Panel)
Contrast Ratio
Viewing Angle(from
centre,CR≥10)
Backlight Lamp Life
Input Video Format
Input Video Signal
Connector
Touch Technology
Touchscreen Interface
Touch Response Time
Touch Sensitivity
Monitor Dimensions
Shipping Carton
Dimensions
Weight(approximately)
Mounting Options
Power Supply
Power Consumption
Temperature Range
Relative Humidity
Typ.
Rise+Fall(Typically)
Horizontal(left/right)
Vertical(up/down)
Hrs to 1/2 brightness
OTL424
42”TFT Open Frame Touch Monitor
Black
Standard
16:9 Ratio 42”Active Matrix TFT LCD
930.24mm×523.26 mm
1920×1080
67.5KHz Horizontal,60Hz Vertical
0.4845mm×0.4845mm
6.5ms(G to G)
VESA DDC 1/2B
Remote OSD with 1.2m cable
16.7M
400cd/㎡
4000:1
178°(89°/89°)
178°(89°/89°)
50,000
RGB Analog / DVI Video
VGA / DVI
Serial/USB
Surface Acoustic Wave(SAW)
Dual Serial/USB
10.4ms
Fixed
1012×612×120 (mm)
1189×253×753(mm)
Monitor
Non Condensing
Agency Approvals
43.5KG
Side Mount
External:100-240VAC,50-60Hz
240 W Max
Operating:0 -40 ,Storage:-20 -60
Operating:20%-80%,Storage:10%-90%
FCC,CE,RoHS
Touch Your IMAGINATIONToday
World Trade SpA
- Via della Lontra, 43 - 47923 Rimini Italy
Tel. +39 0541 75.33.44 - Fax +39 0541 75.33.38 - [email protected]
www.worldtrade.it
World Trade SpA - Official European Distributor
TMGT-OTL42FH
42" REAR TOUCH MONITOR
Wo r l d L e a d i n g
To u c h S o l u t i o n s
P r ov i d e r
Appendix
Drawing:
