by World Trade SpA
RMLT-4258
42" REAR OPEN FRAME MONITOR
Features
Open Frame
Slim prof ile with u niq u e narrow border
Mu ltiple mou nting options
Open-f rame VESA mou nting option and remov able wing bracket f or VESA
Detach able cables f or easy cable h arnessing
Single power su pply f or all optional dev ices
Mu ltilingu al and detach able On Screen Display ( OSD)
Comb Serial and USB tou ch interf ace
Su per-sensitiv e, drif t-f ree, precise tou ch with no ov erlay
Long-lasting produ ct cycle
Worldwide agency approv als
Model
TM-3258
Description
32” TFT Open Frame Tou ch monitor
Case/ Bez el Color
Black
Display
16 :9 Ratio 32” Activ e matrix TFT LCD
Optimal( nativ e) resolu tion
136 6 X 76 8@6 0Hz
World Trade SpA
- Via della Lontra, 43 - 47923 Rimini Italy
Tel. +39 0541 75.33.44 - Fax +39 0541 75.33.38 - [email protected]
www.worldtrade.it
by World Trade SpA
RMLT-4258
42" REAR OPEN FRAME MONITOR
Leadingtou ch Open Frame LCD’ s tou ch monitors are designed f or easy
integration into kiosk, gaming mach ine, indu strial enclosu re and oth er
installations wh ere compact, tou ch -integrated display are pref erred.
RM-4258 integrates th e Leadingtou ch ’ s IP 6 5 lev el Inf rared
tou ch screen, RM-4258 series is Du stproof and Waterproof tou ch monitors.
RM-4258 is designed f or space sav ing and easy mou nting integrations.
Th e Open Frame conf igu ration along with optional siz e mou nting brackets
wou ld enable you to easily cu stomiz e into kiosks, cabinets, in-wall as well
as oth er enclosu res.
RM-4258 will h av e Leadingtou ch Combo interf ace with du al tou ch ports
f or conv enience and f lexibility. It will enable you
to u se both
th e Serial
RS-232 as well as USB port f or you r tou ch application.
Model
RM-4258
Description
42” TFT Open Frame Tou ch Monitor
Case/ Bez el Colou r
Black
Tou ch monitor P erf ormance
Standard
Display Type
16 :9 Ratio42” Activ e Matrix TFT LCD
Activ e Display Area
930* 523mm
Nativ e Resolu tion
1920 x 1080 @ 6 0Hz
Sych roniz ation Range
135 K Hz h oriz ontal, 120 Hz Vertical
P ixel Response Time Rise + Fall
8ms
P lu g and P lay
VESA DDC 1/ 2B
On Screen Display ( OSD)
Remote OSD with 1.2m Cable
Colou rs
10bit( D) , 1.06 Billon colors
Brigh tness ( From Centre, CR> = 5)
550 cd/ m²
Contrast Ratio Typically
1100:1
Viewing Angle Horiz ontal ( lef t/ righ t)
180º( 90º/ 90º)
Viewing Angle Vertical ( u p/ down)
180º( 90º/ 90º)
Backligh t Lamp lif e
50000 Hrs to ½ brigh tness
Inpu t Video Format
Analog ( VG A) and DVI
Monitor Dimensions
1007* 6 00* 117mm
Carton Dimensions
1135* 855* 315mm
Weigh t ( approximately)
Mou nting Options
40.5kg( net) / 45kg( sh ipping)
Rear Mou nt, VESA 75 & 100mm, Inclu ded
P ower Su pply
External: 100-240V, 50-6 0 Hz
P ower Consu mption
16 0 Watts Typical
Temperatu re Range
Operating:0ºC-50ºC, Storage:-20ºC-6 0ºC
Relativ e Hu midity
Operating:10% -90% , Storage 10% -90%
Agency Approv als
RoHS, CE, FCC
World Trade SpA
- Via della Lontra, 43 - 47923 Rimini Italy
Tel. +39 0541 75.33.44 - Fax +39 0541 75.33.38 - [email protected]
Non Condensing
www.worldtrade.it
by World Trade SpA
RMLT-4258
42" REAR OPEN FRAME MONITOR
REMOTE
OSD
220V AC P ower
USB
RS232
EAR
P HONE
P C
AUDIO
TV
AV2
S
VIDEO
AV1
VG A
HDMI
ACTIVE AREA
ACTIVE AREA
Detail A
SIDE MOUNT, HORIZONTAL
VESA
SIDE MOUNT,
VERTICAL
SIDE MOUNT,
VERTICAL
SIDE MOUNT, HORIZONTAL
REAR MOUNT WITH BRACKETS,
HORIZONTAL AND VERTICAL
RECOMMENDED CUSTOMER
PANEL CUT-OUT
World Trade SpA
- Via della Lontra, 43 - 47923 Rimini Italy
Tel. +39 0541 75.33.44 - Fax +39 0541 75.33.38 - [email protected]
www.worldtrade.it
by World Trade SpA
RMLT-4258
42" REAR OPEN FRAME MONITOR
Optional Accessory: Remote OSD Controller Box
144
134
124
ON/OFF
EXIT/SELECT
RIGHT
LEFT
MENU
AUTO
42
10
2-? 3.5
15
1200
