DATA SHEET
ITEM NUMBER REFIL 50651
Personal Protective Equipment (PPE)
Folded respirator with exhalation valve - Approval FFP3D NR (EN
149:2001+ A1:2009) – CE 1024 -Individual Packaging – Yellow colour
REFIL 50651 protects from dust, very toxic fumes and aerosol of minimum protection up to 40x the OEL
value (Occupational Exposure Limits) (max. value laboratory tested =50xOEL).
Approved with dolomite dust
Laboratory trials carried out at the renowned NELSON LABORATORIES INC., Salt Lake City, Utah, USA,
which certificated the filtering efficiency of REFIL 50651 against viruses and bacteria
Minimum filtering efficiency 98% (Norma European EN 149)
Respiration resistance:
Max. level allowed
100 Pa
300 Pa
300 Pa
Breathing in (30 l/min.) 46,5 Pa
Breathing in (95 l/min.) 137,1 Pa
Breathing out (160 l/min.) 120,8 Pa
Filtering material made of:
•
•
•
•
non-woven protective layer
double non-woven filtering layer of electrete microfibres (PP fibres)
non-woven filtering layer
non-woven protective layer
Filtering efficiency in relation to dimension of the OEL (NaCL test)
Application:
•
•
•
•
•
•
•
•
•
Pharmaceutical and chemical
industry
Laboratories
Health environment
Bacterium and viruses prevention
Construction, asbestos disposal
Welding
Nuclear industry
Toxic waste disposal (asbestos
etc.)
Ni-Cd battery manufacturing
Packaging:
•
•
•
•
PU = 100 units (10 x 10)
each dispenser box contains 10 pieces
individual packaging reduces risk of contamination
folded flat – easily stored in a pocket
Sede: Via Trieste, 13 A – 16018 Mignanego (GE) tel. 010/7720317 fax 010/7721741
Deposito: Località Pratolino – 19037 Santo Stefano Magra (SP) tel. 0187/630194 fax 0187/696434
P. IVA: 02255230100 e-mail: [email protected] web: www.icea.it
Instruction for use
1. Open the respirator
respirator nose clip
2. Preform nose clip by
according to the picture
by
outstretching
gently
bending
3. Position the respirator under your chin with
the nose clip up and pull the straps over your
head
4. Mould the nose clip to the shape of your
nose by pressing it between your fingers
5. Check the fit of respirator: inhale sharply.
However, should you detect the ingress of
air, improve respirator tightness by
- correcting the respirator position
- readjusting the nosepiece
- correcting the position of the straps
Valid since 22.06.2010
