DATA SHEET – ITEM NUMBER 50641
Personal Protective Equipment (PPE)
Folded respirator with exhalation valve and active charcoal against
nuisance odours and organic vapours. Approval FFP2 NR (EN 149:2001+
A1:2009) – CE 1024 -Individual Packaging - Grey colour
REFIL 50641 protects from dust, toxic fumes and aerosol of minimum protection up to 12x the OEL
value (Occupational Exposure Limits) and from odours and organic vapours (e.g. solvents, varnish and
splashes) with a concentration < than the OEL.
Minimum filtering efficiency 92% (Norma European EN 149)
Respiration resistance:
Max. level allowed
70 Pa
240 Pa
300 Pa
Breathing in (30 l/min.) 33,6 Pa
Breathing in (95 l/min.) 106,2 Pa
Breathing out (160 l/min.) 163,4 Pa
Filtering material made of:





non-woven protective layer
double non-woven filtering layer of electrete microfibres
(PP fibres)
non-woven protective layer
filtering Polyester non-woven layer with active carbon
non-woven protective layer
Filtering efficiency in relation to dimension of the OEL (NaCL test)
Application:






Engineering industry
Agriculture
Construction
Shipbuilding
Hospital and Residential home
Laboratories
Unpleasant smells and organic vapours






Metalwork incl. sandpapering
Welding
Varnishing
Health environment
Hospital and Residential home
Laboratories
Packaging:




PU = 150 units (10 x 15)
each dispenser box contains 15 pieces
individual packaging reduces risk of
contamination
folded flat – easily stored in a pocket
Sede: Via Trieste, 13 A – 16018 Mignanego (GE) tel. 010/7720317 fax 010/7721741
Deposito: Località Pratolino – 19037 Santo Stefano Magra (SP) tel. 0187/630194 fax 0187/696434
P. IVA: 02255230100 e-mail: [email protected] web: www.icea.it Instruction for use
1. Open the respirator
respirator nose clip
2. Preform nose clip by
according to the picture
by
outstretching
gently
bending
3. Position the respirator under your chin with
the nose clip up and pull the straps over your
head
4. Mould the nose clip to the shape of your
nose by pressing it between your fingers
5. Check the fit of respirator: inhale sharply.
However, should you detect the ingress of
air, improve respirator tightness by
- correcting the respirator position
- readjusting the nosepiece
- correcting the position of the straps
The disposal of the product depends on the contaminant which it came into contact with during use and must be made in
compliance with the rules in force in the country of use.
Valid since 15/07/2013
