GUARNIZIONI PER
PNEUMATICA
PNEUMATIC PACKINGS
PROFILI DELLE GUARNIZIONI
SEAL DESIGNS
Profilo
Drawing
Codice
Code
Descrizione
Description
Materiale
Material
Durezza
(Shore A)
Hardness
Applicazione
Application
Pressione
Operativa
(Bar) (Max)
Working
Pressure
Temperatura
Operativa (C°)
(Max)
Working
Temperature
Corsa
(m/sec)
Sliding
Speed
Pagina
Page
TENUTE STELO COMBINATE / COMBI ROD SEALS
GPS01
TENUTE STELO COMBINATE
COMBI ROD SEAL
PU
92
STELO
ROD
16
-30+80
1.0
114
GPS03
TENUTE STELO COMBINATE
COMBI ROD SEAL
NBR
PU
90
92
STELO
ROD
12
16
-30+105
-30+80
1.0
1.0
116
GPS04
TENUTE STELO COMBINATE
COMBI ROD SEAL
NBR/TPE
PU/TPE
80
92
STELO
ROD
16
16
-30+105
-30+80
1.0
1.0
118
TENUTE PISTONE / PISTON SEALS
GPP05
PISTONE COMPLETO
COMPLETE PISTON SEAL
TENUTA PISTONE
GPP01 PISTON SEAL
NBR
75
PISTONE
PISTON
16
-30+105
1.0
122
NBR
PU
80
80
PISTONE
PISTON
12
16
-30+105
-30+80
1.0
1.0
124
GPP02
TENUTA PISTONE COMPATTA
COMPACT PISTON SEAL
NBR
70
PISTONE
PISTON
12
-30+105
1.0
126
GPP03
TENUTA PISTONE
PISTON SEAL
NBR
PU
80
80
PISTONE
PISTON
12
16
-30+105
-30 + 80
1.0
1.0
128
GPP04
TENUTA PISTONE
PISTON SEAL
NBR
70
PISTONE
PISTON
12
-30+105
1.0
130
PU
92
STELO
ROD
16
-30+80
1.0
134
PTFE / BRONZO
PTFE / BRONZE
_
PISTONE STELO
PISTON ROD
_
-60+200
15
138
ANELLI SMORZATORI / DAMPER
SMORZATORE
GPS02 DAMPER SEALS
FASCE GUIDA / GUIDE BANDS
FG03 FASCIA GUIDA
MRB GUIDE BAND
112
