BTR-12000D
6236
5812
12059
7926
13582
MARKING
5447
13579
5808
13577
13583
7859
13578
PIN
6283
7428
5803 5804 5805 5806
5816
12149
5625
10864
714
7917
13004
6283
5825
13576
5799
13234
6283
6286
6283
113
13603
5823
3600
4049
13601
7419
113
2981
7616
14489
7418
10348
13580
14490
13575
540
7204
9379
13573
3600
13574
7588
13644
7616
13574
7616
13573
8654
6172
13602
3016
6780
13599
3017
693
3019
113
13224
13223
13594
13593
3043
12062
7599
13581
13592
5850
13591
13243
13590
13595
3561
13598
6127
13572
4675
13600
13604
13574
13605
13584
5820
642
3034
2963
266
642
7594
50
10697
7579
7432
5042
642
13589
3033
2605
13188
5859
13596
13597
13588
642
13585
4362
743
4362
743
13188
13586
8776
4362
13587
(1SD999503U)
Part No.
RD 0050
RD 0113
RD 0266
RD 0540
RD 0642
RD 0693
RD 0714
RD 0743
RD 2605
RD 2963
RD 2981
RD 3016
RD 3017
RD 3019
RD 3033
RD 3034
RD 3043
RD 3561
RD 3600
RD 4049
RD 4362
RD 4675
RD 5042
RD 5447
RD 5625
RD 5799
RD 5803
RD 5804
RD 5805
RD 5806
RD 5808
RD 5812
RD 5816
RD 5820
RD 5823
RD 5825
RD 5850
Please note that the number of adjusting washers
may not be the same as shown in the exploded views.
(Adjustment will vary with each individual product.)
Description
Screw
Washer
C Lock
Screw
Screw
Free Spool Tension Washer
Rotor Nut
Washer
Clutch Pawl Spring
BaitRunner Click Spring
Free Spool Tension Spring
Click Gear
Free Spool Tension Washer
Free Spool Tension Screw
BaitRunner Ratchet
Spacer
Free Spool Tension Shaft
Screw
Screw
Washer
Screw
Screw
Anti-Reverse Cam Ring
Roller Clutch Assembly
Line Roller Spacer
Rotor Nut Retainer
Bail Spring Guide A
Spring Guide A Support
Bail Spring
Bail Spring Guide B
Washer
Screw Collar
Bail Trip Lever
Spacer
Lever Spring Guide A
Lever Spring Guide B
BaitRunner Pawl Spring
Part No.
RD 5859
RD 6127
RD 6172
RD 6236
RD 6283
RD 6286
RD 6780
RD 7204
RD 7418
RD 7419
RD 7428
RD 7432
RD 7579
RD 7588
RD 7594
RD 7599
RD 7616
RD 7859
RD 7917
RD 7926
RD 8654
RD 8776
RD 9379
RD10348
RD10697
RD10864
RD12059
RD12062
RD12149
RD13004
RD13188
RD13223
RD13224
RD13234
RD13243
RD13572
RD13573
Description
Spacer
Screw
Bail Hold Support Shaft
Screw
Screw
Bail Trip Lever Spring
Single Eared Washer
Lock Washer
Screw
Screw
Bail Trip Lever Washer
Anti-Reverse Cam
Anti-Reverse Cam Spring
Spool Support
Bail Hold Support Spacer
Friction Ring
Spool Washer
Screw
Line Roller Bushing
Screw
Drag Washers Retainer
Oil Cap
Screw
Click Spring
Anti-Reverse Lever
Line Roller
Screw
Line Roller Support
Line Roller Washer
Line Roller Collar
Ball Bearing
Dial Retainer
Dial Retainer B
BaitRunner Tension Dial
Clutch Spring
Drag Knob
Key Washer
Part No.
RD13574
RD13575
RD13576
RD13577
RD13578
RD13579
RD13580
RD13581
RD13582
RD13583
RD13584
RD13585
RD13586
RD13587
RD13588
RD13589
RD13590
RD13591
RD13592
RD13593
RD13594
RD13595
RD13596
RD13597
RD13598
RD13599
RD13600
RD13601
RD13602
RD13603
RD13604
RD13605
RD13644
RD14489
RD14490
Description
Drag Washer
Spool Assembly
Main Shaft
Spacer
Bail Arm
Bail Spring Cover
Rotor
Bail Assembly
Ball Bearing
Pinion Gear
Pinion Gear Bushing
Drive Gear
Side Cover
Handle Assembly
BaitRunner Lever Arm L
BaitRunner Lever Bridge
Oscillating Slider Retainer
Oscillating Slider
Oscillating Gear
Oscillating Gear Bushing
E Pin
BaitRunner Lever Shaft
Clutch Plate Assembly
Clutch Pawl
BaitRunner Pawl
Dial Click
BaitRunner Pawl Guide
Body I.D. Plate
Body
BaitRunner Lever Arm R
Handle Screw Cap
Eared Washer
Eared Washer
Screw
Drag Click
(231121)
