BLUE LINE
INDEX
GENERAL CONDITIONS AND TERMS OF SALE
PAG.
1
SP E
Undercounter glass-dishwashers single skin
DP E
Undercounter glass-dishwashers double skin
4
FW
Fresh water glasswashers double skin
5
ACCESSORIES
Glass-dishwasher racks
6-7
ACCESSORIES
Saucers insert, cutlery baskets and base stands
8-9
ACCESSORIES
Gastronorm racks 500 x 500 mm in polypropylene
SP 68 E - SP81 E
Free standing dishwasher single skin
12
SO
Pass through dishwashers hood type
12
ACCESSORIES
Tables and accessories for SO 55E / 100 / 120
13
ACCESSORIES
Water treatment, drain and detergent pumps
14-15
TR - E
Rack conveyor dishwashers
16-17
ACCESSORIES
Optional accessories for
TR - E series rack conveyor machines
ACCESSORIES
Tables for TR - E series rack conveyor machines
21
SP 68 E - LO 50 E 2°
Utensil washers single skin
22
LO 2a
Utensil washers double skin
23
ACCESSORIES
Utensil washer racks
24
ACCESSORIES
Utensil washer accessories
25
HLC
Basket washer conveyor type
26
HGL
Flight conveyor warewasher
27
2-3
10-11
18-19-20
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 13:55 Pagina 1
BLUE LINE
GENERAL CONDITIONS AND TERMS OF SALE
DELIVERY TERMS
☛ Immediate for machines available in stock.
☛ 30 days for machines
series FW, SP-E, DP-E, SO, LO.
☛ 60 days for machines series TR-E - HLC - HGL.
☛ 24 hours for urgent spare parts (term subject to
availability in stock).
☛ 7 days for ordinary spare parts orders.
Hoonved Srl reserves the right to despatch the goods on different
terms according to production and customer necessities.
GOODS FREIGHT
All goods are rendered ex Hoonved’s factory. The risk and the cost of
transportation are at customer’s charge and responsibility, even in
case Hoonved undertakes delivery by own or third means and on
behalf of the purchaser.
PACKAGING
In carton included. Wood cage package implies a surcharge of 3%
calculated on goods price. At cost for undercounter models.
WARRANTY
12 months from the date of installation or maximum 18 months from
the date of delivery from Hoonved s.r.l. Warranty covers all parts
resulting defective from factory with the exclusion of electrical parts,
wearing parts and labour.
No warranty is applicable to third par ties other than the ones
undertaking sales/purchase contract with Hoonved s.r.l.
INSTALLATION AND COMMISSIONING OF GOODS.
Any installation and commissioning costs are excluded from our
prices.
VALUE ADDED TAX (VAT)
Not included in list prices and therefore at purchaser’s charge.
PAYMENT TERMS
To be agreed.
PROPERTY OF GOODS
According to art. 1523 of the Italian Civil Code the goods object of the
contract and sold by Hoonved Srl. are subject to property reservation
untill full payment has been made. The unpayment of any portion of
the price automatically resolve the contract and entitles Hoonved Srl to
claim all relevant damages.
COMPETENT COURT
The contracts stipulated with Hoonved Srl are subject to the Italian
law. For any dispute, either in Italy or abroad, the Milan court shall be
the competent one.
SPECIAL VOLTAGES AVAILABLE ON REQUEST WITH SURCHARGE
Iscrizione Registro Produttori AEE IT8020000000334
1
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 13:55 Pagina 2
SP-E SERIES
BLUE LINE
Undercounter glass and dishwashers
SPR 36 code 54000J
1.384,00
Rotating rack glasswasher
SPR 36 D code 54020J
1.598,00
Rotating rack glasswasher with built-in water softener
Electrical connection V230 / 1 / 50 Hz
Rack size Ø mm 360
Machine dimensions mm 430 x 490 x 600 H
Door clearance mm 235
Cycle min. 2’
SPB 35 code 54244J
Fixed square rack glasswasher
1.341,00
SPB 35 code 54243J
Fixed round rack glasswasher
1.341,00
Electrical connection V230 / 1 / 50 Hz
Rack size mm 350 x 350 / Ø 360
Machine dimensions mm 430 x 515 x 576 H
Door clearance mm 235
Cycle min. 2’
SP 35 E code 56011J
Fixed square rack glasswasher
1.508,00
SP 35 E code 56013J
1.487,00
Fixed round rack glasswasher
code 56046J square rack
SP 35 DE code 56047J round rack
Fixed rack glasswasher with built-in water softener
1.716,00
1.694,00
Electrical connection V230 / 1 / 50 Hz
Rack size mm 350 x 350 / Ø 360
Machine dimensions mm 430 x 525 x 675 H
Door clearance mm 280
Cycle min. 2-3-4’
All fixed rack glasswashers can be used with round racks having the dimensions as the square ones.
For the best results and for the utmost reliability and durability of the machine, all glass and dishwashers must work with water
whose hardness is between 4° and 10° French degrees.
2
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 13:56 Pagina 3
SP-E SERIES
BLUE LINE
Undercounter glass and dishwashers
56012J square rack
SP 40 E code
code 56014J round rack
1.698,00
Fixed rack glasswasher
56015J square rack
SP 40 DE code
code 56016J round rack
1.910,00
Fixed rack glasswasher with built-in water softener
Electrical connection V230 / 1 / 50 Hz
Rack size mm 400 x 400 / Ø 400
Machine dimensions mm 460 x 525 x 675 H
Door clearance mm 280
Cycle min. 2-3-4’
SP 45 E code 56001J
Fixed rack dishwasher
2.299,00
SP 45 DE code 56017J
2.513,00
Fixed rack dishwasher with built-in water softener
Electrical connection V400 / 3N / 50 Hz
Rack size mm 450 x 450
Machine dimensions mm 530 x 605 x 755 H
Door clearance mm 270
Cycle min. 2-3-4’
SP 5 code 56008J
2.338,00
Fixed rack dishwasher
SP 5 E BT cod. 56096J
2.784,00
Lavapiatti a cesto fisso con sistema break tank
SP 5 DE code 56019J
2.550,00
Fixed rack dishwasher with built-in water softener
Electrical connection V230 / 1 / 50 Hz
Rack size mm 500 x 500
Machine dimensions mm 600 x 605 x 820 H
Door clearance mm 330
Cycle min. 2-3-4’
SP 50 E code 56000J
Fixed rack dishwasher
SP 50 E BT cod. 56030J
2.588,00
3.034,00
Lavapiatti a cesto fisso con sistema break tank
SP 50 DE code 56018J
2.802,00
Fixed rack dishwasher with built-in water softener
Electrical connection V400 / 3N / 50 Hz
Rack size mm 500 x 500
Machine dimensions mm 600 x 605 x 820 H
Door clearance mm 330
Cycle min. 2-3-4’
All fixed rack glasswashers can be used with round racks having the dimensions as the square ones.
For the best results and for the utmost reliability and durability of the machine, all glass and dishwashers must work with water
whose hardness is between 4° and 10° French degrees.
3
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 13:56 Pagina 4
DP-E SERIES
BLUE LINE
Double skin undercounter glass and dishwashers
DP 35 E
code 57002J square rack
code 57009J round rack
Fixed rack glasswasher
1.947,00
DP 35 DE code 57005J
2.175,00
Fixed rack glasswasher with built-in water softener
Electrical connection V230 / 1 / 50 Hz
Rack size mm 350 x 350 / Ø 360
Machine dimensions mm 430 x 530 x 700 H
Door clearance mm 280
Cycle min. 2-3-4’
57001J square rack
DP 40 E code
code 57010J round rack
2.038,00
Fixed rack glasswasher
code 57006J square rack
code 57012J round rack
Fixed rack glasswasher with built-in water softener
DP 40 DE
2.249,00
Electrical connection V230 / 1 / 50 Hz
Rack size mm 400 x 400 / Ø 400
Machine dimensions mm 480 x 530 x 700 H
Door clearance mm 280
Cycle min. 2-3-4’
DP 45 E code 57003J
Fixed rack dish washer
2.488,00
DP 45 DE code 57007J
2.699,00
Fixed rack dishwasher with built-in water softener
Electrical connection V400 / 3N / 50 Hz
Rack size mm 450 x 450
Machine dimensions mm 530 x 620 x 755 H
Door clearance mm 270
Cycle min. 2-3-4’
DP 50 E code 57000J
Fixed rack dishwasher
2.853,00
DP 50 E BT cod. 57031J
3.299,00
Lavapiatti a cesto fisso con sistema Break Tank
DP 50 DE code 57008J
3.063,00
Fixed rack dishwasher with built-in water softener
Electrical connection V400 / 3N / 50 Hz
Rack size mm 500 x 500
Machine dimensions mm 600 x 620 x 820 H
Door clearance mm 330
Cycle min. 2-3-4’
All fixed rack glasswashers can be used with round racks having the dimensions as the square ones.
For the best results and for the utmost reliability and durability of the machine, all glass and dishwashers must work with water
whose hardness is between 4° and 10° French degrees.
4
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 13:56 Pagina 5
FW SERIES
BLUE LINE
Fresh water glasswashers, double skin construction, energy saving device
FW 35
code 54500J square rack
code 54501J round rack
2.449,00
Fixed rack glasswasher
Electrical connection V400 / 3N / 50 Hz
Rack size mm 350 x 350 / Ø 360
Machine dimensions mm 430 x 485 x 690 H
Door clearance mm 225
Cycle min. 2.30’’
code 54520J square rack
code 54521J round rack
Fixed rack glasswasher
FW 40
2.652,00
Electrical connection V400 / 3N / 50 Hz
Rack size mm 400 x 400 / Ø 400
Machine dimensions mm 480 x 540 x 735 H
Door clearance mm 280
Cycle min. 2.30’
FW 45 code 54540J
2.888,00
Fixed rack glasswasher
Electrical connection V400 / 3N / 50 Hz
Rack size mm 450 x 450
Machine dimensions mm 530 x 600 x 755 H
Door clearance mm 280
Cycle min. 2.30’’
FW 50 code 54560J
3.404,00
Fixed rack glasswasher
Electrical connection V400 / 3N / 50 Hz
Rack size mm 500 x 500
Machine dimensions mm 600 x 605 x 810 H
Door clearance mm 320
Cycle min. 2.30’
All fixed rack glasswashers can be used with round racks having the dimensions as the square ones.
For the best results and for the utmost reliability and durability of the machine, all glass and dishwashers must work with water
whose hardness is between 4° and 10° French degrees.
5
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 13:57 Pagina 6
ACCESSORIES
BLUE LINE
Glass and dishwasher racks
Code 25132
Polipropylene round net rack h 140 mm
26,00
Dimensions mm Ø 360
For models 35-36
Code 15411
Round net rack h 170 mm
40,00
Dimensions mm Ø 360
For models 35-36
Code 15412
Round net rack h 190 mm
49,00
Dimensions mm Ø 360
For models 35-36
Code 15414
Round net rack h 170 mm
47,00
Dimensions mm Ø 400
For models 40
Code 15415
Round net rack h 230 mm
56,00
Dimensions mm Ø 400
For models 40
Code 15417
Round net rack h 170 mm
53,00
Dimensions mm Ø 450
For models 45
Code 15537
Round net rack h 170 mm
61,00
Dimensions mm Ø 500
For models 5-50-81
Code 15420
Square net rack
56,00
Dimensions mm 350 x 350 - For models 35
Code 15421
Square net rack
59,00
Dimensions mm 400 x 400 - For models 40
Code 15524
Square net rack
65,00
Dimensions mm 450 x 450 - For models 45
Code 15525
Square net rack
80,00
Dimensions mm 500 x 500 - For models 50-81
Code 34275
S/s net rack mesh 25x25
217,00
Dimensions mm 500 x 500 - For models 5-50-81- SO55 - 100 - 120
Code 17379
Square pizza plate n. 12 Ø 32 cm rack
Dimensions mm 500 x 500 - For models 5-50-81- SO55 - 100 - 120
6
83,00
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 13:57 Pagina 7
ACCESSORIES
BLUE LINE
Glass and dishwasher racks
Code 36027
53,00
Insert champagne glasses for square net racks Code 15420-15421-15524-15525
Code 37862
Insert champagne glasses for square plastic rack Code 18075
Code 34486
Square rack inclinated glasses n. 3 compartments for beer Weizen
40,00
114,00
Dimensions mm 350 x 350 - For models 35-36
Code 17645
Square rack inclinated glasses
118,00
n. 4 compartments for glasses - Dimensions mm 400 x 400
Code 17646
Square rack inclinated glasses
120,00
n. 4 compartments for glasses - Dimensions mm 450 x 450
Code 34501
Square rack inclinated glasses
129,00
n. 5 compartments for glasses - Dimensions mm 500 x 500
Code 34735
Rack inclinated hanging stem glasses
118,00
Dimensions mm 400 x 400 - For models 40
Code 35203
Rack inclinated hanging stem glasses
120,00
Dimensions mm 450 x 450 - For models 45
Code 35204
126,00
Rack inclinated hanging stem glasses
Dimensions mm 500 x 500- For models 50
Code 15499
8 plates square rack
61,00
Dimensions mm 400 x 400 - For models 40
Code 15545
14 plates square rack
70,00
Dimensions mm 450 x 450 - For models 45
Code 15541
18 plates square rack
77,00
Dimensions mm 500 x 500 - For models 5 - 50-81
Code 15582
20 plates square rack
86,00
Dimensions mm 500 x 500 - For models 5 - 50- 81- SO 55 - 100 - 120
Code 34502
26 plates square rack rilsan covered
90,00
Dimensions mm 500 x 600 - For models LO 50 E 2° - SP 68 E
7
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 13:57 Pagina 8
ACCESSORIES
BLUE LINE
Glass and dishwasher racks
Code 15495
15 saucers insert for 350 mm rack - For model 35 - 43
11,00
Code 15462
17 saucers insert for 400 mm rack - For model 46-48
13,00
Code 15463
20 saucers insert for 450 mm rack - For model 53
15,00
Code 15464
2 places teaspoon basket
7,00
Code 15465
4 places cutlery basket
11,00
Code 25134
8 places cutlery basket
20,00
Code 35430
Single cutlery basket
Code 37861
9,00
47,00
8 places cutlery basket
Dimensions mm 250 x 500
to insert (2 pcs) in the rack 26683
Code 33933
500 x 500 mm cutlery rack
Dimensions mm 500 x 500 x 75 H
For models 5 - 50- 81- SO 55 - 100 - 120
8
69,00
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 13:58 Pagina 9
ACCESSOIRES
BLUE LINE
Glass and dishwasher racks
Base stand height 500 mm
Dimensions mm 600 x 565 x 500 H
Code 55006
Code 55000
Code 55007
Code 55001
Code 55002
Code 55003
278,00
SPB 35 - SPR 36
SP 35 E - DP 43 E - FW 35
SP 40 E
DP 40 E - FW 40
SP 43 E - DP 45 E - FW 45
SP 5 E - SP 50 E - FW 50
Base stand closed on three sides with guides
Code 55008
SP 68 E
Dimensions mm 600 x 656 x 430 H + mm 30 feet standard
Code 55009
SP 5 E - SP 50 E - DP 50 E - FW 50
Dimensions mm 600 x 565 x 430 H + mm 30 feet standard
Code 37868
Kit 4 adjustable feet 150/220 mm for closed base stand in stailess steel
361,00
351,00
103,00
Code 37859
Round net plastic basket mm Ø 400 x 180 H
For mod. 40
38,00
Code 36184
8 plates plastic net rack mm 400 x 400 x 110 H
For mod. 40
53,00
Code 37954
Square plastic net rack mm 350 x 350 x 120 H
21,00
Code 37860
Square plastic net rack mm 350 x 350 x 150 H
26,00
Code 35862
Square plastic net rack mm 400 x 400 x 110 H
29,00
Code 18075
Square plastic net rack mm 400 x 400 x 150 H for rack code 37862
33,00
Square plastic net rack mm 400 x 400x 110 H with inserts:
Code 37911 36 places
62,00
Code 37910 25 places
62,00
Code 37909 16 places
62,00
9
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 13:58 Pagina 10
ACCESSORIES
BLUE LINE
Gastronorm racks in polypropilene
Code 26683
Base net rack
63,00
Dimensions mm 500 x 500 x 75 H - For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
65,00
Code 33912
Base net rack and 1 frame
Dimensions mm 500 x 500 x 100 H - For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
Code 33913
Base net rack and 2 frames
89,00
Dimensions mm 500 x 500 x 150 H - For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
Code 33914
Base net rack and 3 frames
103,00
Dimensions mm 500 x 500 x 200 H - For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
65,00
Code 26686
18/12 plate rack
Dimensions mm 500 x 500x 100 H
For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
99,00
Code 33917
12 pizza plate rack
Dimensions mm 500 x 500
For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
77,00
Code 33918
16 glass rack
Dimensions mm 500 x 500 x 100 H
For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
H. 65
H. 100
Code 33919
16 glass rack
Dimensions mm 500 x 500 x 150 H
For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
92,00
H. 115
H. 150
111,00
Code 33920
16 glass rack
Glass diameter
MAX Ø 110 mm
Dimensions mm 500 x 500 x 200 H
For models5 - 50 - 81 - SO 55 - 100 - 120 - TR
H. 165
H. 200
Code 33921
16 glass rack
Dimensions mm 500 x 500 x 250 H
For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
120,00
H. 215
H. 250
Code 33922
25 glass rack
Dimensions mm 500 x 500 x 100 H
For models 60-81/ CAP 7 E -10-12 / TR-E
77,00
H. 65
H. 100
Code 33923
25 glass rack
Dimensions mm 500 x 500 x 150 H
For models 60-81/ CAP 7 E -10-12 / TR-E
92,00
H. 115
H. 150
111,00
Code 33924
25 glass rack
Dimensions mm 500 x 500 x 200 H
For models 60-81/ CAP 7 E -10-12 / TR-E
Glass diameter
MAX Ø 85 mm
H. 165
H. 200
Code 33925
25 glass rack
120,00
Dimensions mm 500 x 500 x 250 H
For models 60-81/ CAP 7 E -10-12 / TR-E
10
H. 215
H. 250
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 13:58 Pagina 11
ACCESSORIES
BLUE LINE
Gastronorm racks
103,00
Code 33926
25 inclinated glass rack
Dimensions mm 500 x 500 x 100 H
For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
H. 65
H. 100
120,00
Code 33927
25 inclinated glass rack
Dimensions mm 500 x 500 x 150 H
For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
Glass diameter
MAX Ø 74 mm
H. 115
H. 150
137,00
Code 33928
25 inclinated glass rack
Dimensions mm 500 x 500 x 200 H
For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
H. 165
H. 200
77,00
Code 33929
36 glass rack
Dimensions mm 500 x 500 x 100 H
For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
H. 65
H. 100
96,00
Code 33930
36 glass rack
Dimensions mm 500 x 500 x 150 H
For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
Glass diameter
MAX Ø 74 mm
H. 115
H. 150
118,00
Code 33931
36 glass rack
Dimensions mm 500 x 500 x 200 H
For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
H. 165
H. 200
Code 33932
36 glass rack
Dimensions mm 500 x 500 x 250 H
For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
153,00
H. 215
H. 250
Code 37200
Tray rack
79,00
Dimensions mm 500 x 500 x 75 H For models 5 - 50 - 81 - SO 55 - 100 - 120 - TR
Code 37703
Tray rack
92,00
Dimensions mm 500 x 500 x 75 H For models series 5 - 50 - 68 - 81 - SO
Code 55510
Rack trolley with handle
347,00
For gastronorm racks
Code 55511
Rack trolley without handle
220,00
For gastronorm racks
11
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 13:59 Pagina 12
SP-E SERIES
BLUE LINE
Dishwashers 700 p/h
SP 68 E cod. 56007J PB
Universal undercounter dishwasher
3.244,00
SP 68 E BT cod. 56064J
Universal undercounter dishwasher with Break tank system
3.690,00
SP 68 DE
3.547,00
cod. 56020J PB
Universal undercounter dishwasher with built-in water softener
Electrical connection V400 / 3N / 50 Hz
Rack size mm 500 x 600
Machine dimensions mm 600 x 690 x 830 H
Door clearance mm 400 - Cycle min. 2-3-4’
SP 81 E cod. 56009J Free standing dishwasher electronic control digital display 700 p/h
3.453,00
SP 81 E BT
3.899,00
cod. 56097J
Free standing dishwasher electronic control digital display 700 p/h
with Break tank system
Electrical connection V400 / 3N / 50 Hz
Rack size mm 500 x 500
Machine dimensions mm 600 x 685 x 1315 H
Door clearance mm 400 - Cycle sec. 55-85-120 intensive 8 min.
Per
vedere pag 27
SO SERIES
Dishwashers 550 - 1200 p/h
Pass through dishwasher electronic timer
SO 55 E cod. 58537J
4.195,00
Pass through dishwasher with electronic timer with tank filters 550/(700) p/h*
Electrical connection V400 / 3N / 50 Hz
Rack size mm 500 x 500
Machine dimensions mm 625 x 725 x 1420 H
Door clearance mm 380
Cycle sec. 120 - 180 -240
* rack 15582 available as optional
For the best results and for the utmost reliability and durability of the machine, all glass and dishwashers must work with water whose hardness
is between 4° and 10° French degrees.
12
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 13:59 Pagina 13
SERIE SO
BLUE LINE
Dishwashers 550 - 1200 p/h
Pass through dishwasher with electronic control and digital display
SO 100 E cod. 58500J
4.809,00
Pass through dishwasher with electronic control digital display 1000 p/h
SO 100 E BT cod. 58505J
5.231,00
Pass through dishwasher with electronic control digital display 1000 p/h
and break tank system
SO 100 DE cod. 58554J
Pass through dishwasher with built-in water softener
5.299,00
Electrical connection V400 / 3N / 50 Hz
Rack size mm 500 x 500
Machine dimensions mm 625 x 740 x 1460 H
Door clearance mm 420
Cycle sec. 65-100-150 intensive 8 min.
Thermal-acoustic insulated hood
SO 120 E cod. 58501J
440,00
5.296,00
Pass through dishwasher with electronic control digital display 1200 p/h
SO 120 E BT cod. 58547J
Pass through dishwasher with electronic control digital display 1200 p/h
and break tank system
5.742,00
SO 120 DE cod. 58555J
Pass through dishwasher with built-in water softener
5.786,00
Electrical connection V400 / 3N / 50 Hz
Rack size mm 500 x 500
Machine dimensions mm 625 x 740 x 1460 H
Door clearance mm 420
Cycle sec. 55-85-120 intensive 8 min.
Thermal-acoustic insulated hood
Per
440,00
vedere pag 27
SO 150 E BT cod. 58543J
lavastoviglie a capote controllo elettronico display digitale 1560 p/h
con sistema break tank
8.034,00
Allacciamento elettrico V400/3N/50Hz
Cesto mm 500 x 600
Dimens. macchina mm 725 x 760 x 1560 h
H utile mm 540
Ciclo sec. 60 -120-180 intensivo 180 HDP
capote con isolamento termo-acustico
RCC
Per
vedere pag 27
440,00
1.900,00
recuperatore di calore “RCC” per SO 100-120-150
fornito separatamente
consigliato su macchine con isolamento termo-acustico
Per il miglior funzionamento e durata tutte le lavastoviglie devono operare con acqua la cui durezza sia tra 4° e 10° francesi.
Qualora l’alimentazione idrica non rientri in questi parametri è indispensabile ll’installazione di un addolcitore d’acqua.
13
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 14:00 Pagina 14
ACCESSORIES
SX = LEFT
DX = RIGHT
BLUE LINE
Tables for pass through models SO 55 E - 100 - 120
SX & DX code 55068
600 mm shelf table
183,00
Dimensions mm 600
ONLY FOR MODEL SO 55 E
SX & DX code 55069
600 mm table - Dimensions mm 600 - For models SO 55 E - 100 - 120
309,00
SX & DX code 55070
800 mm table - Dimensions mm 800 - For models SO 55 E - 100 - 120
567,00
SX & DX code 55071
1000 mm table - Dimensions mm 1000 - For models SO 55 E - 100 - 120
658,00
SX & DX code 55072
1200 mm table - Dimensions mm 1200 - For models SO 55 E - 100 - 120
746,00
SX & DX code 55073
1800 mm table - Dimensions mm 1800 - For models SO 55 E - 100 - 120
1.205,00
SX code 55088
DX code 55074
1200 mm table with sink and rear splash shield
1.667,00
Dimensions mm 1200 - For models SO 55 E - 100 - 120
SX code 55091
DX code 55075
1800 mm table with sink and rear splash shield
2.177,00
Dimensions mm 1800 - For models SO 55 E - 100 - 120
SX code 55090
DX code 55076
1800 mm table with sink, waste hole and rear splash shield
2.304,00
Dimensions mm 1800 - For models SO 55 E - 100 - 120
Code 55512
Wheeled waste bin
492,00
Dimensions mm Ø 370 x 600 H
14
Code 55513
Extractable shower hose
203,00
Code 55514
Flexible shower hose
542,00
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 14:00 Pagina 15
ACCESSORIES
BLUE LINE
For glass and dishwashers
Pre-fitted built-in drain pump for SP-E - DP E
Add “PS” after machine code
Pre-fitted built-in drain pump for SP81E, SO 55 E - 100 - 120
182,00
277,00
Add “PS” after machine code
Drain pump KIT
Code 34090 SPB 35-SPR 36
Code 36913 SP 35 E - SP 40 E - DP 35 E - DP 40 E
Code 36907 SP 45 E - SP 5 E - SP 50 E - SP 68 E - DP 45 E - DP 50 E
101,00
Code 34469 SP81E
218,00
Code 37058 SO 55 E - LO 56
165,00
Code 36574 SO 100 - 120
211,00
Pre-fitted built-in detergent pump for models SP E - DP E - FW
183,00
Add “PD” after machine code
Code 36943
Kit detergent pump for internal fitting on models SP E - DP E - FW
142,00
Code 34558
Kit accessories for the connection of the detergent pump (32570)
On SP E - DP E models
38,00
Pre-fitted built-in detergent pump
for models SP81E, SO 55E - 100 - 120
280,00
Add “PD” after machine code
Code 35376
Kit detergent pump for internal fitting
On models SP81E, SO 55E - 100 - 120
245,00
Code 32570
Detergent pump wall mounted
170,00
Code 35168
Kit accessories for the connection of detergent pump (32570)
C81E / CAP 7E - 10 - 12
Booster pump built-in
For SP81E, SO 55E - 100 - 120
42,00
297,00
Add “PP” after machine code
Code 35429
Booster pump kit for SP81E, LO 50 E 2°, SO 55E - 100 - 120
274,00
Code 32598
Rinse booster pump external
for models SP E - DP E - FW (pump only)
214,00
15
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 14:00 Pagina 16
ACCESSORIES
BLUE LINE
Water treatment
Code 37863
Brita - Purity 1200 clean
897,00
Code 37864
Brita - Purity 1200 clean extra
897,00
Code 37865
Cartridge filter for Purity 1200 clean
196,00
Code 37866
Cartridge filter for Purity 1200 clean extra
196,00
The non-return of the exhausted filters implies
a charge each of
Code 55558
Reverse osmosis system Dometic
31,00
4.738,00
Dimensions mm 250 x 395 x 490 H
16
Code 30093
Automatic water softener 8 kg
979,00
Code 26243
Water softener 8 lts.
177,00
Code 26394
Water softener 12 lts.
192,00
Code 29507
Water softener 16 lts.
237,00
Listino inglese linea blu:Listino inglese 1a p 37961 15/11/10 14:00 Pagina 17
TR-E SERIES
BLUE LINE
Rack conveyor dishwashers
TR-E 90 SX code 55200
TR-E 90 DX code 55201
11.294,00
Rack conveyor dishwasher electric heating 95 racks/h-1710 plates/h
TR-E 90 V SX code 55202
TR-E 90 V DX code 55203
1300
Direction left-right (SX)
13.006,00
Rack conveyor dishwasher steam heated 95 racks/h-1710 plates/h
Electrical connection V400 / 3N / 50 Hz
Machine dimensions mm 1300x800x1410 H
Clearance mm 500 x 430 (h)
Unit = wash with rinse
Double wall with thermal-acoustic insulation
and counterbalanced doors
TR-E 100 SX code 55204
TR-E 100 DX code 55205
1.136,00
13.973,00
Rack conveyor dishwasher electric heating 80/120 racks/h-1440/2160 plates/h
TR-E 100 V SX code 55206
TR-E 100 V DX code 55207
200
1300
Direction left-right (SX)
15.780,00
Rack conveyor dishwasher steam heated 80/120 racks/h-1440/2160 plates/h
Electrical connection V400 / 3N / 50 Hz
Machine dimensions mm 1500 x 800 x 1410 H
Clearance mm 500 x 430 (h)
Unit = wash with rinse
Double wall with thermal-acoustic insulation
and counterbalanced doors
TR-E 150 SX code 55212
TR-E 150 DX code 55213
1.136,00
18.859,00
Rack conveyor dishwasher electric heating 97/146 racks/h-1746/2628 plates/h
TR-E 150 V SX code 55214
TR-E 150 V DX code 55215
20.745,00
Rack conveyor dishwasher steam heated 97/146 racks/h-1746/2628 plates/h
200
500
1300
Direction left-right (SX)
Electrical connection V400 / 3N / 50 Hz
Machine dimensions mm 2000 x 800 x 1410 H
Clearance mm 500 x 430 (h)
Unit = light prewash + wash with rinse
Double wall with thermal-acoustic insulation
and counterbalanced doors
1.681,00
For the best results and for the utmost reliability and durability of the machine, all glass and dishwashers must work with water
whose hardness is between 4° and 10° French degrees.
17
Listino inglese 2a p 37961:Listino inglese 2a p 37961 15/11/10 13:48 Pagina 18
TR-E SERIES
BLUE LINE
Rack conveyor dishwashers
TR-E 170 SX code 55220
TR-E 170 DX code 55221
20.330,00
Rack conveyor dishwasher electric heating 115/173 racks/h - 2070/3114 plates/h
TR-E 170 V SX code 55222
TR-E 170 V DX code 55223
22.362,00
Rack conveyor dishwasher steam heated 115/173 racks/h - 2070/3114 plates/h
200
1300
600
Direction left-right (SX)
Electrical connection V400 / 3N / 50 Hz
Machine dimensions mm 2100 x 800 x 1710 H
Clearance mm 500 x 430 (h)
Unit = light prewash + wash with rinse
Double wall with thermal-acoustic insulation
and counterbalanced doors
TR-E 200 SX code 55236
TR-E 200 DX code 55237
1.795,00
25.557,00
Rack conveyor dishwasher electric heating 131/197 racks/h-2358/3546 plates/h
TR-E 200 V SX code 55238
TR-E 200 V DX code 55239
28.113,00
Rack conveyor dishwasher steam heated 131/197 racks/h-2358/3546 plates/h
200
1300
900
Direction left-right (SX)
Electrical connection V400 / 3N / 50 Hz
Machine dimensions mm 2400 x 800 x 1710 H
Clearance mm 500 x 430 (h)
Unit = heavy prewash + wash with rinse
Double wall with thermal-acoustic insulation
and counterbalanced doors
TR-E 230 SX code 55252
TR-E 230 DX code 55253
2.119,00
33.462,00
Rack conveyor dishwasher electric heating 149/224 racks/h-2682/4032 plates/h
TR-E 230 V SX code 55254
TR-E 230 V DX code 55255
200
900
900
1300
Direction left-right (SX)
36.809,00
Rack conveyor dishwasher steam heated 149/224 racks/h-2682/4032 plates/h
Electrical connection V400 / 3N / 50 Hz
Machine dimensions mm 3300x 800 x 1710 H
Clearance mm 500 x 430 (h)
Unit = heavy prewash + 1st wash + 2nd wash with rinse
Double wall with thermal-acoustic insulation
and counterbalanced doors
3.100,00
For the best results and for the utmost reliability and durability of the machine, all glass and dishwashers must work with water
whose hardness is between 4° and 10° French degrees.
18
Listino inglese 2a p 37961:Listino inglese 2a p 37961 15/11/10 13:48 Pagina 19
ACCESSORIES
For TR-E series
AS
200
600
600
1300
For further information you can require
the book “ACCESSORIES”
BLUE LINE
Power Rinse
• Energy and water saving system for rinse function (PR)
1.756,00
Code 55523
Drying section 600 mm 6,8 kW (AS).
4.045,00
Code 55519
Drying section 600 mm steam heated (AS).
4.360,00
Code 55563
Drying section curved version 90° 1000 x 1000 mm 6,8 kW (AS).
7.880,00
Code 55564
Drying section curved version 90° 1000 x 1000 mm
steam heated (AS).
8.195,00
Double wall with thermo-acoustic insulation
526,00
Code 55601
Drying section reinforced (ASR).
4.676,00
Code 55602
Drying section reinforced 600 mm steam heated (ASR)
5.043,00
Code 55603
Drying section reinforced on curved version 90°
1000x1000 mm 10,6 kW (ASR).
8.510,00
Code 55604
Drying section reinforced on curved version 90°
1000x1000 mm steam heated (ASR).
8.878,00
ASR
200
600
600
1300
CV
Double wall with thermo-acoustic isulation
526,00
Powered Boiler
• To require when the machine is connected to cold water
(without RC).
716,00
AS
Code 55605
Steam condensing system (CV)
• Equipped with cooling battery
• It condenses the steams coming out of the machine
200
600
600
1300
RC
200
600
1300
3.520,00
AS
600
Code 55606
Steam condensing system (RC) 12 mq for mod. TR-E 90-100-150
3.730,00
Code 55607
Steam condensing system (RC) 24 mq for mod. TR-E 170-200-230
5.516,00
• Equipped with electro-ventilator with battery
• It allows to connect the machine to cold water and reduces temperature
and humidity of the room
• For proper function to be combined with drying section
19
Listino inglese 2a p 37961:Listino inglese 2a p 37961 15/11/10 13:48 Pagina 20
ACCESSORIES
For TR-E series
HP
200
1300
600
AS
600
For further information you can require
the book “ACCESSORIES”
Heat pump (HP4)
• Equipped with heat recovery unit and freezing circuit
• It allows to connect the machine to cold water.
It reduces temperature and humidity
of the room saving lot of energy.
• To be applied on all the TR-E models
on request
Heat pump (HP6)
• Equipped with heat recovery unit and freezing circuit
• It allows to connect the machine to cold water.
It reduces temperature and humidity of the
room saving lot of energy.
• To be applied only starting from model TR-E 170
on request
Code 55608
Splash guard 200 mm
• Standard feature on inlet on all TR-E model but the TR-E 90
200
20
1300
BLUE LINE
547,00
200
Code 55526 inlet LEFT - Code 55527 inlet RIGHT
Side loading table
Dimensions: mm 710 x 595 x 880 H
1.881,00
Code 55556
90° rack unloading table with motorized rollers
Dimensions: mm 700 x 700 x 880 H
4.771,00
Prewashing on curve 90° for TR-E 170
Prewashing on curve 90° for TR-E 200 and TR-E 230
on request
Code 55518
Rinse booster pump for TR-E series
Code 55525
Manual auto stop device for stop of machine in absence of racks
Code 55600
Rinse aid injector
Code 55536
Liquid detergent inejctor
1.156,00
810,00
603,00
586,00
Listino inglese 2a p 37961:Listino inglese 2a p 37961 15/11/10 13:49 Pagina 21
ACCESSORIES
for TR-E series
For further information you can require
the book “ACCESSORIES”
BLUE LINE
Code 55530
Roller conveyor mm 1000
1.289,00
Code 55534
Roller conveyor mm 1500
1.930,00
Code 55531
End limit switch for roller conveyor
Code 55555
Roller conveyor curve 90 ° - mm 1300 x 1300
Code 55531
End limit switch for roller conveyor
295,00
3.184,00
295,00
Code 55529
Mechanical curve unit 90° - mm 1000 x 1000
3.910,00
Code 55553
Motorized curve unit 90° - mm 1000 x 1000
5.458,00
Code 55552
Motorized curve unit 180° - mm 1000 x 1500
6.993,00
Code 55543
Sorting table mm 1700 x 1150 x 880 H
Code 55544
Sorting table mm 2200 x 1150 x 880 H
Code 55545
Sorting table mm 2700 x 1150 x 880 H
2.403,00
Code 55546
Wall mounted rack shelf mm 1070 x 525 x 570 H
Code 55547
Wall mounted rack shelf mm 1570 x 525 x 570 H
Code 55548
Wall mounted rack shelf mm 2070 x 525 x 570 H
Code 55549
Floor mounted rack shelf mm 1070 x 525 x 570 H
Code 55550
Floor mounted rack shelf mm 1570 x 525 x 570 H
Code 55551
Floor mounted rack shelf mm 2070 x 525 x 570 H
2.707,00
3.023,00
843,00
1.150,00
1.294,00
918,00
1.429,00
1.551,00
21
Listino inglese 2a p 37961:Listino inglese 2a p 37961 15/11/10 13:50 Pagina 22
ACCESSORIES
Tables for TR-E series
For further information you can require
the book “ACCESSORIES”
Code 55086 Left and right
Load-unload table mm 600
567,00
Code 55078 Left and right
Load-unload table mm 800
615,00
Code 55079 Left and right
Load-unload table mm 1000
709,00
Code 55080 Left and right
Load-unload table mm 1200
797,00
code 55081 Left and right
Load-unload table mm 1800
1.290,00
Attention : when the machine Mod. TR-E is equipped with splash
guard you have to require the table with prolonged under shelf .
Please add after the code reference the letter S
87,00
Code 55082 Left and right
Table mm 1200 with sink and rear splash shield
1.816,00
Code 55083 Left and right
Table mm 1800 with sink and rear splash shield
2.375,00
Attention : when the machine Mod. TR-E is equipped with splash
guard you have to require the table with prolonged under shelf .
Please add after the code reference the letter S
Code 55084 Left and right
Table mm 1800 with sink,waste hole and rear splash shield
Attention : when the machine Mod. TR-E is equipped with splash
guard you have to require the table with prolonged under shelf .
Please add after the code reference the letter S
22
BLUE LINE
87,00
2.494,00
87,00
Code 55513
Extractable shower hose
203,00
Code 55514
Flexible shower hose
542,00
Listino inglese 2a p 37961:Listino inglese 2a p 37961 15/11/10 13:50 Pagina 23
SP-E SERIES
BLUE LINE
Utensil washers single skin
Utensil washer undercounter model with electronic timer
SP 68 E
3.244,00
SP 68 E BT
cod. 56064J lavaoggetti universale sottobanco con sistema Break Tank
3.690,00
SP 68 DE
3.547,00
code 56007J
Universal undercounter warewasher
code 56020J
Universal undercounter warewasher with built-in water softener
Electrical connection V400 / 3N / 50 Hz
Rack size mm 500 x 600
Machine dimensions mm 600 x 695 x 830 H
Door clearance mm 400
Cycle min. 2-3-4’
Compact utensil washer electronic control with digital display
LO 50 E 2° code 59022J
5.359,00
Multipurpose utensil washer electronic control with digital display
LO 50 E BT 2° cod. 59020J
5.805,00
Lavaoggetti polivalente con display, con sistema Break Tank
LO 50 DE 2° code 59023J
5.849,00
Multipurpose utensil washer electronic control with digital display,
built-in water softener and rinse booster pump
Electrical connection V400 / 3N / 50 Hz
Rack size mm 500 x 600
Machine dimensions mm 620 x 735 x 1380 H
Door clearance mm 500
Washing times min. 2 - 4 - 6 - 10 min. (max)
For
see pag 27
RCC
1.900,00
Recuperatore di calore “RCC” montato su LO 50 E
For the best results and for the utmost reliability and durability of the machine, all glass and dishwashers must work with water whose hardness
is between 4° and 10° French degrees.
23
Listino inglese 2a p 37961:Listino inglese 2a p 37961 15/11/10 13:50 Pagina 24
LO SERIES 2a
BLUE LINE
Utensil washers double skin
Compact utensil washer electronic control with digital display
LO 56 BT - 2° cod. 54780J
8.209,00
Compact utensil washer electronic control with digital display
and break tank system
Double wall construction
Electrical connection V400 / 3N / 50 Hz
Washing space mm 540 x 660 x 825 H
Machine dimensions mm 707 x 810 x 1860 H (mm 2200 open door)
Washing times min 2/4/6/10 (max)
Insulation Thermal-acoustic “PC”
595,00
RCC condensing unit mounted on LO 56
2.500,00
LO 67 - 2° cod. 54750J
9.108,00
Compact utensil washer electronic control with digital display
LO 67 BT - 2° cod. 59105J
10.348,00
Compact utensil washer electronic control with digital display
and break tank system
Double wall construction
Electrical connection V400 / 3N / 50 Hz
Washing space mm 650 x 700 x 650 H
Machine dimensions mm 830 x 915 x 1890 H (mm 2150 open door)
Washing times min 2/4/6/10 (max)
Insulation Thermal-acoustic “PC”
LO 83 - 2° cod. 54760J
638,00
12.763,00
Compact utensil washer electronic control with digital display
LO 83 BT - 2° cod. 59106J
13.445,00
Compact utensil washer electronic control with digital display
and break tank system
Double wall construction
Electrical connection V400 / 3N / 50 Hz
Washing space mm 810 x 700 x 650 H
Machine dimensions mm 990 x 915 x 1890 H (mm 2150 open door)
Washing times min 2/4/6/10 (max)
Insulation Thermal-acoustic “PC”
For
708,00
see pag 27
For the best results and for the utmost reliability and durability of the machine, all glass and dishwashers must work with water whose hardness
is between 4° and 10° French degrees.
24
Listino inglese 2a p 37961:Listino inglese 2a p 37961 15/11/10 13:50 Pagina 25
LO SERIES 2a
BLUE LINE
Utensil washers double skin
Compact utensil washer electronic control with digital display
EDI 13 - 2° code 54770
Utensil washer electronic control with digital display
17.068,00
EDI 13 BT - 2° code 59107
17.750,00
Utensil washer electronic control with digital display
and break tank system
Double wall construction
Electrical connection V400 / 3N / 50 Hz
Washing space mm 1320 x 700 x 650 H
Machine dimensions mm 1500 x 915 x 1890 H (mm 2150 open door)
Washing times min 2/4/6/10 (max)
Insulation Thermal-acoustic “PC”
EDI 13 alta - 2° code 54772
846,00
17.956,00
Utensil washer electronic control with digital display
EDI 13 alta BT - 2° code 59108
18.638,00
Utensil washer electronic control with digital display
and break tank system
Double wall construction
Electrical connection V400 / 3N / 50 Hz
Washing space mm 1320 x 700 x 820 H
Clearance mm 800 H
Machine dimensions mm 1500 x 915 x 2040 H (mm 2305 open door)
Washing times min 2/4/6/10 (max)
Insulation Thermal-acoustic “PC”
For
846,00
see pag 27
cod. 640601
Heat pump HP2 for LO 67 and LO 83
6.780,00
cod. 640600
Heat pump HP3 for LO 134 and LO 134alta
7.670,00
For the best results and for the utmost reliability and durability of the machine, all glass and dishwashers must work with water whose hardness
is between 4° and 10° French degrees.
25
Listino inglese 2a p 37961:Listino inglese 2a p 37961 15/11/10 13:51 Pagina 26
ACCESSORIES
BLUE LINE
Utensil and warewasher racks
Code 34441
S/s net rack mesh 25 x 25
295,00
Size mm. 500 x 600 - for models LO 50 E
Code 35802
S/s net rack mesh 25 x 25
320,00
Size mm. 600 x 700 - for models LO 62
Code 35073
S/s net rack mesh 50 x 50
352,00
Inner dimension size mm 650 x 700 - for models LO 67
Code 35074
S/s net rack mesh 25 x 25
412,00
Inner dimension size mm 810 x 700 - for models LO 83
Code 35075
S/s net rack mesh 50 x 50
504,00
Inner dimension size mm 1320 x 700 - for models LO 134
Code 35178
S/s cover for net rack
124,00
Size mm 590 x 480 - for model LO 50 E
Code 34911
S/s cover for net rack
140,00
Size mm 694 x 644 - for models LO 67 - 83 - 134
Code 37459
S/s baking pan insert 75 mm slots
253,00
Size mm 484 x 585 - For models LO 50 E - SP 68 E
Code 37458
S/s baking pan insert 85 mm slots
274,00
Size mm 530 x 650 - For models LO 62 - LO 56
Code 35675
S/s baking pan insert mm 80 slots
Size mm 570 x 590 - For models LO 67 - LO 134
260,00
Code 35676
S/s baking pan insert mm 75 slots
352,00
Size mm 690 X 800 - For models LO 83
Code 18239
Cone holder for sac à poche
For models SERIES LO
26
45,00
Listino inglese 2a p 37961:Listino inglese 2a p 37961 15/11/10 13:51 Pagina 27
ACCESSORIES
BLUE LINE
Accessories for utensil washers
HDMS 1 - Basic HACCP
Monitoring system for external PC
301,00
External serial interface for connecting PC SO 55 - 100 - 120, SP 81 E, LO 50 E 2°, LO 56 - 67 - 83 - 134 2°
(PC-cables & Software included)
HDMS 2 - LogBox HACCP
Cycle memory function on-board
819,00
External serial interface for connecting PC to on-board LogBox SO 55 - 100 - 120, SP 81 E,
LO 50 E 2°, LO 56 - 67 - 83 - 134 2° (PC-cables & Software included)
HDMS 3 LogBox Modem GSM HACCP
On-board telediagnose system with GSM-SMS or PC-modem
1.342,00
GSM system with LogBox for SO 55 - 100 - 120, SP 81 E, LO 50 E 2°, LO 56 - 67 - 83 - 134 2°
(Subscription of SIM-card for data and SMS transmission not included)
Pre-fitted detergent pump LO 56-67-83-134, LO 50 E 2°, LO 62
Add “PD” after machine code
292,00
Code 35376
KIT detergent pump assembly LO 56-67-83-134, LO 50 E 2°, LO 62
245,00
External shower pre-fitted LO 56-67-83-134
Add “DC” after machine code
304,00
Code 35189
KIT External shower LO 56-67-83-134
241,00
Pre-fitted drain pump LO 62-67-83-134 series
369,00
Pre-fitted drain pump LO 50 E 2°, LO 56, SO 55E
Add “PS” after machine code
272,00
Code 36040
KIT drain pump LO 67 - 83 - 134
297,00
Code 37917 / 36015
KIT drain pump for internal fitting on LO50E 2°, LO62
218,00
Code 37058
KIT drain pump for internal fitting on LO56 - SO55E
165,00
Pre-fitted wheels “RU” LO 56-67-83-134, LO 50 E 2°
Add “RU” after machine code
376,00
Code 35210
Wheels LO 56-67-83-134, LO 50 E 2°
297,00
Rinse booster pump pre-fitted LO 67
Add “PR” after machine code
Code 35212
KIT rinse booster pump LO 67
547,00
441,00
Rinse booster pump pre-fitted LO 50 E 2°
Add “PR” after machine code
290,00
Code 35429
Booster pump kit for SP 81 E / LO 50 E 2° / SO 55 - 100 - 120
274,00
27
Listino inglese 2a p 37961:Listino inglese 2a p 37961 15/11/10 13:51 Pagina 28
HLC SERIES
BLUE LINE
Basket washer conveyor type
HLCR SX code 54855
HLCR DX code 54856
15.690,00
Basket conveyor dishwasher eletric heating
Electrical connection V400 / 3N / 50 Hz
Machine dimensions mm 2100x860x1650 H (mm 1950 H door open)
Clearance mm 500 x 430 H
Steam heating on request
Direction left-right (SX)
HLC2R SX code 54857
HLC2R DX code 54858
25.176,00
Basket conveyor dishwasher eletric heating
Electrical connection V400 / 3N / 50 Hz
Machine dimensions mm 3000 x 860 x 1650H (mm 1950 H door open)
Clearance mm 500 x 430 H
Steam heating on request
Direction left-right (SX)
HLC SX
HLC DX
code 54838
code 54839
18.457,00
Basket conveyor dishwasher eletric heating
Electrical connection V400 / 3N / 50 Hz
Machine dimensions mm 2100x860x1860 H (mm 2150 H door open)
Clearance mm 500 x 630 H
Steam heating on request
Direction left-right (SX)
HLC2 SX
HLC2 DX
code 54840
code 54841
Basket conveyor dishwasher eletric heating
Electrical connection V400 / 3N / 50 Hz
Machine dimensions mm 3000 x 860 x 1860 H (mm 2150 H door open)
Clearance mm 500 x 630 H
Steam heating on request
Direction left-right (SX)
26
29.621,00
copertina INGLESE 37961:copertina INGLESE 37961 15/11/10 14:21 Pagina 4
HGL SERIES
BLUE LINE
Flight conveyor warewashers
HGLR SX code 54824
HGLR DX code 54825
on request
Conveyor speed 0,49 - 1,96 m/min.
HGLR V SX code 54826
HGLR V DX code 54827
Direction left-right (SX)
on request
Electronic control
Double wall with thermal-acoustic insulation and counterbalanced doors
Electrical connection V400 / 3N / 50 Hz
Machine dimensions mm 3900 x 1080 x 1990 H (mm 2740 H door open)
Clearance mm 850 x 430 H
HG2LR SX code 54828
HG2LR DX code 54829
on request
Conveyor speed 0,79 - 3,16 m/min.
HG2LR V SX code 54830
HG2LR V DX code 54831
Direction left-right (SX)
on request
Electronic control
Double wall with thermal-acoustic insulation and counterbalanced doors
Electrical connection V400 / 3N / 50 Hz
Machine dimensions mm 5200 x 1080 x 1990 H (mm 2740 H door open)
Clearance mm 850 x 430 H
For information on the above machines
please contact our sales department
The manufacturer reserves the right to change specifications and photos without notice.
29
cod. 37961 - Ed. 11-2010 - fratelliCrespi industria grafica Cassano M.
copertina INGLESE 37961:copertina INGLESE 37961 15/11/10 14:21 Pagina 1
