STATIONARY
BATTERIES
OPzS
range
THE MIDAC OPzS LOW MAINTENANCE STANDBY POWER BATTERIES
Midac OPzS are Low Maintenance Standby Tubular Plate
Batteries designed as reserve power supply for all
industrial applications where low maintenance as well as
medium and long discharge rates are required.
4
5
6
5
6
7
6
7
8
9
10
11
12
12
13
14
15
16
20
24
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
OPzS
200
250
300
350
420
490
600
700
800
900
1000
1100
1200
1500
1625
1750
1875
2000
2500
3000
Voltage CAPACITY
Ah/C10
(Volt)
1,80 V
(
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
)
200
250
300
350
420
490
600
700
800
900
1000
1100
1200
1500
1625
1750
1875
2000
2500
3000
Weights (Kg)
Dimensions (mm)
Electrolyte
Pillars
L
W
H
with acid
empty
weight (Kg)
volume (litres)
(NO.)
103
124
145
124
145
166
145
191
191
233
233
275
275
275
399
399
399
399
487
576
206
206
206
206
206
206
206
210
210
210
210
210
210
210
214
214
214
214
212
212
430
430
430
546
546
546
721
721
721
721
721
721
721
871
847
847
847
847
847
847
18,6
22,3
25,9
29,3
34,5
39,4
47,6
56,1
63,9
71,2
77,4
84,1
90,3
113,2
125,2
137,3
147,4
156,6
196,4
229,7
14,5
17,1
19,7
21,8
25,5
29,4
35,2
41,3
47,4
52,2
56,9
61,3
65,7
85,6
95,3
103,8
109,6
117,0
146,7
167,2
4,1
5,2
6,2
7,5
9,0
10,0
12,4
14,8
16,5
19,1
20,5
22,8
24,6
27,6
29,9
33,5
37,8
39,6
49,7
62,5
3,3
4,2
5,0
6,0
7,3
8,1
10,0
11,9
13,3
15,4
16,5
18,4
19,8
22,3
24,1
27,0
30,5
31,9
40,1
50,4
2
2
2
2
2
2
2
4
4
4
4
4
4
4
6
6
6
6
8
8
ADVANTAGES
MAIN APPLICATIONS
√ Topping-up every 3 to 5 years in float charge
under normal operating conditions.
√ Long life 15 years in float at 20°C even under cyclic use.
√ Flexible (Cable-Tech) connection system for:
- Easy and fast installation
- Less accessories needed
- Reduced time spent in maintenance and checking
- Reduced Voltage Drops in the connections
- Improved safety against accidental contacts
√ Self discharge lower than 3% / month
√ Very low floating current
REFERENCE STANDARDS: DIN 40736-1
With its OPzS battery range, MIDAC offers clean and reliable
energy, suitable for back-up a wide range of applications, like:
√
√
√
√
√
√
√
Telecommunications
Railways
Substations
Power generation
Nuclear power stations
UPS
Wind and Solar Energies
-
DIN EN 50272-2
-
CEI EN 60896-1
MIDAC QUALITY ASSURANCE
The batteries described above are manufactured by Midac Spa in Soave (Verona) - Italy, that operates and is certified according to UNI-EN ISO 9001.
MIDAC spa Z.I. 37038 Soave (Verona) Italy - Tel. +39.045.61 32 1 32 - Fax +39.045.61 32 1 34 - www.midacbatteries.com - [email protected]
01D .03.2002 . UK
Cell type
The cells are manufactured with large tubular plates with
lead selenium alloys to ensure long life, minimum
maintenance operations and optimal characteristics in
cycling and standby applications.
