3
1
58
57 9 51
E82130002/01
25
2
4
53
18
31
8
52
32
19
20
36
33
21
7
27
47
49
30
54
10
22
38
11
61
14
37
13
63
11
41
23
50
39
34
40
35
48
6
16
11
46
45
29 28
1203
LISTA RICAMBI
CODICE:
8.213.0514
REV.:
DATA INIZIO VAL.:
10/15/2008
DATA INIZIO VAL.:
DESCRIZIONE:
R82130514
10/15/2008
1
DOMUS IR-03 ESH WET&DRY 220-24 0/50-60 EU LAVOR
PRO
01/01/3000
DATA FINE VAL.:
REV.:
CODICE GRUPPO:
1
DESCRIZIONE:
VACUUM CLEANER
01/01/3000
DATA FINE VAL.:
CODICE:
N. TAVOLA:
DESCRIZIONE:
E82130002/01
QTA':
POS:
4.208.0321
HANDLE FOR PROFESS.VACUUM CLEA NERS
1
01
4.208.0441
HEAD FOR PROFESSIONAL VAC, BLACK, SUITABLE FOR POWER TOOL SOCKET
1
02
3.099.0138
GERMAN SOCKET SEAT 50x50 IP54 COLOUR BLACK -S220E-
1
03
5.009.0538
SWITCH ASSY + PROTECTION COVER 14 (14)
1
04
4.012.0225
ELECTRIC CABLE 3x1, MT 7,5
1
06
4.208.0400
UNDER COVER 2 MOTOR
1
07
5.009.0213
SWITCH WITH PROTECTION 16(8) 12(10)
1
08
3.401.0109
DOUBLE BLACK SWITCH WITH PROTECTION
1
09
4.208.0086
SPACER
1
10
6.205.0108
SPONGE KIT
1
11
3.755.0069
UNIVERSAL MOTOR 230V/50HZ
2
13
4.208.0293
MOTOR BASE x PROF.VACUUM CLEA. '03 (DARK GREY RAL.7016)
1
16
4.208.0096
FLOATING FOR DOMUS-TAURUS ESP.00
1
18
4.208.0075
BASKET FOR PROFESSIONAL VACUUM CLEANER
1
19
4.208.0076
CONE
1
20
6.205.0107
PLASTIC BAG WITH VALVE KIT
1
21
3.751.0012
INOX BODY DOMUS/TAURUS 430BA SP0.7 D.420XH585 ESP.00
1
22
6.205.0071
KIT GASKET+PIPE UNION FOR PROF ESSIONAL VACCUM
1
23
5.212.0048
KIT 10X PAPER BAG FILTER DANGE EROUS DUST
1
25
5.212.0034
HEPA FILTER WITH KIT OF ASSEMB LY
1
27
4.208.0098
FRONT HANDLE FOR BODY DOMUS TAURUS ESP.00
1
28
4.208.0099
LEVER
1
29
3.099.0454
HOOK 2.05/621 ZNT FOR BODY TAURUS '03
2
30
5.209.0127
COMPLETE CONDUCTIVE FLEXIBLE H HOSE D.40 L=3000MM
1
31
3.753.0019
STEEL CURVED HOSE D. 38.2
1
32
3.753.0020
STEEL HOSE D. 38.2
1
33
3.754.0048
FLAT LANCE D.40
1
34
3.754.0049
ROUND BRUSH D.40
1
35
3.403.0025
ELECTRIC CIRCUITBOARD 230/50C/ DELAY GN
1
36
3.754.0084
BRISTLES FLOOR BRUSH
1
37
3.754.0085
LIQUID FLOOR BRUSH
1
38
6.205.0093
WHEELS KIT
1
39
4.207.0004
AXLE FOR VACUUM CLEANER TAURUS DOMUS D.20 L.500
1
40
4.207.0002
INFERIOR TUBOLAR
1
41
4.208.0093
HANDLE LOCKING LEVER -R- RAL-3020
1
43
3.006.0045
PIVOTTING WHEEL D.75X24 M10X30 FOR DOMUS AND TAURUS
2
45
4.208.0294
BASE FOR TROLLEY DOMUS-TAURUS (DARK GREY RAL.7016)
1
46
3.754.0083
BRUSH D.37 L=400 MM
1
47
4.208.0087
SPACER
1
48
3.551.0050
CHEMICAL PUMP 48W WITH CABLE L=700
1
49
4.215.0020
SPONGE HLC 24 AU SP.60 D.390MM 2MOT
1
50
4.212.0001
WIRING SEZ.1,5 FOR VACUUM CLEANER PROF.
1
51
3.403.0192
MANOSTAT -178mBar 1/8G
1
52
3.403.0193
MANOSTAT -115mBar 1/8G
1
53
4.215.0021
SPONGE HLC 24 AU SP.60 S.340MM 2MOT.
1
54
1
RIF1:
RIF2:
LISTA RICAMBI
CODICE:
8.213.0514
REV.:
DATA INIZIO VAL.:
10/15/2008
DATA INIZIO VAL.:
R82130514
10/15/2008
DESCRIZIONE:
DATA FINE VAL.:
REV.:
CODICE GRUPPO:
1
1
DOMUS IR-03 ESH WET&DRY 220-24 0/50-60 EU LAVOR
PRO
01/01/3000
DESCRIZIONE:
DATA FINE VAL.:
CODICE:
VACUUM CLEANER
01/01/3000
DESCRIZIONE:
N. TAVOLA:
E82130002/01
QTA':
POS:
4.408.0013
GASKET FOR QUICK CONNECTION SOCKET
1
55
4.208.0242
BLACK SWITCH HOLDER WITH HOLE FOR COSTELLATION
1
57
5.209.0080
ASSEMBLY HANDLE+SUPPORT+LEVER
1
58
HANDLE LOCKING LEVER -R- RAL-3020
1
61
4.208.0093
2
RIF1:
RIF2:
