DESCRIZIONE
DESCRIPTION
Compressore TK5K 230V 50Hz
Compressore TK5K 230V 60Hz
Compressore TK8K 400V 50Hz 3Ph
Compressore TK8K 230V 60Hz
Compressore TK15K 400V 50Hz 3Ph
Compressore TK15K 230V 60Hz 3Ph
Scambiatore TK5K
Scambiatore TK8K
Scambiatore TK15K
Valvola termostatica TK5K
Valvola termostatica TK8K
Valvola termostatica TK15K
Valvola a 4 vie TK5K
Valvola a 4 vie TK8K
Valvola a 4 vie TK15K
Condensatore TK5K
Condensatore TK8K
Condensatore TK15K
Raccordo filettato TKE
Ghiera filettata TKE
Manicotto PVC TKE
Termostato TKE 50Hz
Termostato TKE 60Hz
Termostato TKE 50Hz trifase
Termostato TKE 60Hz trifase
Pressostato 0,2 bar NC
Pressostato 42 bar NC
Flussostato
Sonda ambiente TKE
Sonda entrata acqua TKE
Sonda uscita acqua TKE
Sonda mandata TKE
Sonda surriscaldamento TKE
Condensatore 4µF 450V
Condensatore 10µF 450V
Griglia ventilatore TKE d.440
Griglia ventilatore TKE d.556
Ventilatore TKE 50W 230V 50Hz
Ventilatore TKE 50W 230V 60Hz
Ventilatore TKE 160W 230V 50Hz
Ventilatore TKE 160W 230V 60Hz
Ventola premente d.440
Ventola premente d.556
Display termostato TKE
Compressor TK5K 230V 50Hz
Compressor TK5K 230V 60Hz
Compressor TK8K 400V 50Hz 3Ph
Compressor TK8K 230V 60Hz
Compressor TK15K 400V 50Hz 3Ph
Compressor TK15K 230V 60Hz 3Ph
Exchanger TK5K
Exchanger TK8K
Exchanger TK15K
Thermostatic valve TK5K
Thermostatic valve TK8K
Thermostatic valve TK15K
4-way valve TK5K
4-way valve TK8K
4-way valve TK15K
Condenser TK5K
Condenser TK8K
Condenser TK15K
Threaded joint TKE
Threaded ring nut TKE
PVC joint TKE
Thermostat TKE 50Hz
Thermostat TKE 60Hz
Three-phase thermostat TKE 50Hz
Three-phase thermostat TKE 60Hz
Pressure switch 0,2 bar NC
Pressure switch 42 NC
Flow switch
Ambient temperature probe TKE
Water-in temperature probe TKE
water-out temperature probe TKE
Discharge temperature probe TKE
Suction temperature probe TKE
Capacitor 4µF 450V
Capacitor 10µF 450V
Fan grid TKE d.440
Fan grid TKE d.556
Fan motor TKE 50W 230V 50Hz
Fan motor TKE 50W 230V 60Hz
Fan motor TKE 160W 230V 50Hz
Fan motor TKE 160W 230V 60Hz
Fan blade d.440
Fan blade d.556
Thermostat display TKE
Modify:
1
CODE
2.1.144
2.1.141
2.1.145
2.1.142
2.1.146
2.1.143
2.2.008
2.2.009
2.2.010
2.3.269
2.3.271
2.3.273
2.3.270
2.3.272
2.3.274
2.3.317
2.3.318
2.3.319
2.4.117
2.4.165
2.4.182
4.1.092
4.1.136
4.1.095
4.1.137
4.1.093
4.1.094
4.1.106
4.1.135
4.1.138
4.1.139
4.1.140
4.1.141
4.3.089
4.3.157
4.9.045
4.9.046
4.3.133
4.3.153
4.3.135
4.3.154
4.3.155
4.3.156
4.9.036
Drawer:
N
Drawing: Spare Parts TK5K-8K-15K
File: spare_parts_TK5K_TK8K_TK15K
Your.code:
Code:
Tol.
Scale: 1:16 Date: 27/01/2015
Material:
Thickness:
Finishing:
Volume:
Approved:
Drawer:
Matteo
Via A.Sansovino, 35
48124 RAVENNA - ITALY
Tel. +39 0544 408333 Fax 280084
http://www.tecoonline.com
