GUARANTEED
3
YEARS
AEROSOL CON COMPRESSORE A PISTONE PER USO MEDICO
PISTON COMPRESSOR NEBULIZER FOR MEDICAL USE
DATI TECNICI COMPRESSORE
COMPRESSOR TECHNICAL DATA
COMPRESSORE
A PISTONE
COMPRESSOR
PISTON COMPRESSOR
PRESSIONE MASSIMA
350 kPa
MAX PRESSURE
350 kPa
PRESSIONE D’ESERCIZIO
0 ÷ 130 kPa
OPERATING PRESSURE
0 ÷ 130 kPa
PORTATA D’ARIA
15 lt/min
AIR FLOW
15 lt/min
CICLO DI UTILIZZO
CONTINUO
OPERATING CYCLE
CONTINUOUS
RUMOROSITÀ
60 dBA
NOISE LEVEL
60 dBA
DIMENSIONI
37 x 10 x 24H cm
DIMENSIONS
37 x 10 x 24H cm
PESO
2,6 kg
WEIGHT
2.6 kg
CLASSE DI RISCHIO
lla
MDD CLASS
lla
ACCESSORI
ACCESSORIES
AMPOLLA FASTERJET CON SISTEMA VALVOLARE (POLIPROPILENE)
FASTERJET NEBULIZER WITH VALVE SYSTEM (POLYPROPYLENE)
NASALE (POLIPROPILENE)
NOSEPIECE (POLYPROPYLENE)
BOCCAGLIO (POLIPROPILENE) CON VALVOLA (SILICONE)
MOUTHPIECE (POLYPROPYLENE) WITH VALVE (SILICONE)
MASCHERA ADULTO (PVC DOP FREE)
ADULT MASK (PVC DEPH FREE)
MASCHERA PEDIATRICA (PVC DOP FREE)
CHILD MASK (PVC DEPH FREE)
TUBO ARIA (PVC DOP FREE)
AIR TUBE (PVC DEPH FREE)
FILTRO DI RICAMBIO
SPARE FILTER
CAVO DI ALIMENTAZIONE
POWER CORD
0434
(dir. 93/42/EEC)
PCS.
2
MASTER CARTON
DATI TECNICI AMPOLLA
CAPACITÀ
16 ml
FRAZIONE RESPIRABILE
< 5 µm 80%
MMAD (Mass Median Aerodinamic Diameter)
2,11 µm
NEB RATE
0,35 ml/min (60kPa)
÷ 0,80 ml/min (130kPa)
VOLUME RESIDUO
0,7 ml
NEBULIZER TECHNICAL DATA
CAPACITY
16 ml
RESPIRABLE VOLUME
< 5 µm 80%
MMAD (Mass Median Aerodinamic Diameter)
2.11 µm
NEB RATE
0.35 ml/min (60kPa)
÷ 0.80 ml/min (130kPa)
RESIDUAL VOLUME
0.7 ml
